Fuse Block with LED Lights
SKU
260-3454-CP
$28.98
Please Select
Select your product options to view availability.
Key Features:
- High-quality fuse block protects the fusible element from the harsh marine environment and damage
- Features LED indicator lights to let you know when a fuse has blown
- Designed to be use with ATC style fuses (sold separately)
- Tin-plated copper connections offer excellent anti-corrosive properties
- Made of marine-grade Stainless Steel, Nickel-plated Copper, and Polycarbonate for long-lasting use
- Effective over-current protection method to safeguard your wiring in electrical circuits
- Allows for 30A per circuit
- Secure,quick and easy installation with (4) separately sold #10 RH fasteners
- Available in 6 positions and 12 positions
- 6 Position Specifications:
- Input Current: 100A
- Max Voltage: 32VDC
- Input Terminal Rating: M5 threaded studs (100A max)
- Output Terminal Rating: M4 threaded studs (25A max)
- Fuse Type: ATC or ATO fuse
- 12 Position Specifications:
- Input Current: 100A
- Max Voltage: 32VDC
- Input Terminal Rating: M6 threaded studs (100A max)
- Output Terminal Rating: M4 threaded studs (30A max)
- Fuse Type: ATC or ATO fuse
