Resettable Momentary Switch

SKU

As low as: $85.00

Control compatible 12V accessories with a resettable 20A momentary switch.

Color

Product Details

Momentary Operation:
Provides temporary push-button control for compatible 12V marine and automotive accessories.
Resettable Circuit Protection:
Automatically senses over-current conditions and switches the connected load off for resettable protection.
Twenty-Amp Capacity:
Solid-state circuitry supports compatible loads up to 20A DC.
316 Stainless Steel Construction:
Marine-grade stainless steel body provides durability and corrosion resistance in harsh environments.
Bright LED Status Ring:
Illuminated ring clearly indicates power status and remains visible in direct sunlight.
Ignition-Protected Design:
Ignition-protected construction supports installation in compatible marine electrical systems.
Built-In Surge Protection:
Integrated surge protection helps protect the switch and connected circuit.
Compact Dash Installation:
Installs through a 0.75" mounting hole to conserve space on crowded switch panels.

Tech Specs

Operating Voltage	12V DC
Current Rating	20A DC
Switch Function	Resettable momentary
Circuit Type	Solid-state
Body Material	316 stainless steel
Circuit Protection	Automatic over-current trip and reset
Surge Protection	Built in
Ignition Protection	Ignition protected
Environmental Ratings	IP67, IK08, and IP44
Mounting Hole Diameter	0.75"
Wire Lead Length	2'
Status Indicator	LED ring

FAQ

What does 'Resettable' mean?
A 'Resettable' design means the circuit within the switch automatically senses over-current conditions and trips the load off with no additional circuit protection or fuse block required.

What happens when there are over-current conditions?
If the switch senses over-current conditions it will turn the load off and the LED light will shut off. You can reset the switch by pressing the switch again, and if it shuts off again all you need to do is find the fault like you would with a blown fuse and reset it again to correct the issue.

What is the difference between On/Off and Momentary switches?
An On/Off switch turns 'on' with one push and supplies power until pushed again putting it into 'off' mode.

Momentary switches only supply power when continuously pushed. A good example of a momentary switch is a horn- it only sounds when pushed and shuts off when released.
