Short Leaf Design:
Compact mounting leaves are designed to fit doors with a 0.5" thickness.Hidden Leaves:
Mounting leaves remain concealed when the door is closed for a clean finished appearance.Non-Friction Operation:
Piano-style hinge operates without built-in friction for straightforward door movement.316 Stainless Steel:
Corrosion-resistant stainless steel construction is designed to withstand harsh marine environments.Compact Dimensions:
Measures 2.9375" long x 1.125" deep for space-conscious marine door installations.Simple Installation:
Fastens with #6 fasteners sold separately.
Short Leaf Piano Hinge 3"
SKU
058-6090
$28.63
Regular Price
Ships FREE on orders over $150!
Helping Boaters
since 1979
since 1979
Honest Expert
Advice
Advice
100% Satisfaction
Guarantee
Guarantee
Product Details
Tech Specs
| Hinge Style | Piano hinge |
| Friction | Non-friction |
| Material | 316 stainless steel |
| Overall Length | 2.9375" |
| Overall Depth | 1.125" |
| Door Thickness | 0.5" |
| Leaf Design | Short, hidden when door is closed |
| Mounting | #6 fasteners; not included |
